FISIOLASER SCAN HP8 - Plus Line

E
L
1
2
0
8
0
Quantity:

Description

Trolley-mounted equipment for scanning laser therapy, power 8000 mW.



Applying scanning laser therapy, using single or multi diode lasers, makes it possible to treat larger areas that when contact therapy is applied, and to apply the therapy automatically, without the presence of an operator. The rule that applies to all forms of medical treatment applies to Laser treatment as well: the best results are obtained by therapists that have sound medical training, know how to listen to the patient, and have good intuitive skills.



ADVANTAGES TO USING SCANNING LASER THERAPY

  • Scanning laser units run in automatic mode, as they do not require an operator to be present.
  • Using a scanning laser unit makes it possible to treat larger areas that when a contact laser is used.
  • Automatic setting of the treatment area.
  • Scanning area adjustable up to 400 cm²
  • Possibility of connecting an external single / multidiode laser handpiece.



ACCESSORIES SUPPLIED

  • 2 Laser protection goggles
  • 1 Interlock key
  • 1 Smart Card



TARGET POINTING DEVICE CHARACTERISTICS

  • Target pointing device UNI EN 60601-2-22 standard: 2 light-drive
  • Light-drive device: Led-diode
  • Light-drive color: red
  • Light-drive representation on the impact point: Spot with red as colour
Accessories

Accessories

Laser Radiation Protective Goggles

02098
Lens color green, VLT 45%.
Ask for quotation

Personal Smart Card

EL0001
10-pack for planning patients' rehabilitation protocol, so as to make it easier and faster to use the equipment.
Ask for quotation

Carry Case

EL0016
Carry case for the unit transport
Ask for quotation

1-Diode Handpiece - 25mw

EL0028
Handpiece 1 diode, 25mW
Ask for quotation

1-Diode Handpiece - 100mw

EL0030
Handpiece 1 diode, 100mW.
Ask for quotation

3-Diode Handpiece - 75mw

EL0031
Handpiece 3 diode, 75mW.
Ask for quotation

3-Diode Handpiece - 300mw

EL0033
Handpiece 3 diode, 300 mW.
Ask for quotation

5-Diode Handpiece - 500mw

EL0036
Handpiece 5 diode, 500 mW.
Ask for quotation
Technical Spec.

Technical Spec.

Mains power supply:
230 Vac, 50-60Hz, ±10%
Mains power supply (on request):
115 Vac, 50-60Hz, ±10%
Max. mains power absorption:
75VA
Interlock key:
DIN 3-pole contacts
LCD display:
6” B/W screen with encoder
Programmable treatment time:
Up to 99 minutes
Laser diode wavelength emission:
940 nm
Laser risk classification EN60825-1:
4
Medical device class according to EU regulations:
II B
Programmable pulse frequency:
200 ÷ 10000 Hz
Power at source (200 Hz):
160mW
Power at source (10000 Hz):
8000mW
Target pointing device UNI EN 60601-2-22 standard:
2 light-drive
Light-drive device:
LED-diode
Light-drive color:
Red
Light-drive representation on the impact point:
Spot with red as colour
Output channels:
2 independents
Pre-installed protocols:
Available
Storable patient procedures on internal memory:
200
Dimensions:
39 x 43 x 168 h cm
Weight:
35 kg
Gallery

Gallery

Logistics

Logistics

Code Repertoire:
R0800889

Weight, size and volume

Weight, size and volume (+/- 10%)
N° Package Package type Dimension Weight Volume
1 SCATOLA cm 140 x 27 x 32 h kg 9.5 mc 0.12096
2 SCATOLA cm 125 x 61 x 63 h kg 43 mc 0.480375
