Description

TENS digital unit with 2 channels. The TENS ECO 2 includes 12 pre-set programs (such as burst, frequency modulation, muscle stimulation, dynamic stimulation, HAN stimulation) and 12 programs adjustable by the user. The TENS ECO 2 combines high quality pain relief with modern and friendly design.



FEATURES:

  • Digital 2-channel TENS unit
  • 12 pre-set programs for pain management, muscle stimulation and relaxation
  • 12 free programs for own settings TENS stimulation programs: burst, low/high frequency, frequency modulation
  • Special HAN stimulation program for highest levels of pain relief
  • 1 pre-set + 1 free program for muscle stimulation
  • Dynamic stimulation program for relaxation and massage
  • Blue LCD display
  • Interlocking the keypad for increased safety
  • Integrated AKS (controlled output short circuit) for improved skin protection
  • Neck band for easy home use

Integrated rechargeable battery
The TENS ECO 2 works with an integrated rechargeable battery which reduces the long time cost for batteries for both patients and therapists.


Intensity
The intensity of TENS ECO 2 can be raised in steps of 0.5 mA in order to garantee a comfortable stimulation for the patient.


Parameters
The parameters of each program are displayed on the upper left corner of the TENS ECO 2 for a more convenient program selection.



SUPPLIED ACCESSORIES

  • 106351 CABLE 5.15, 2 PIECES
  • 283400 ELECTRODES 50x50 mm, 4 PIECES
  • 104776 BATTERY CHARGER
  • TRANSPORT BAG
Accessories

Accessories

Medicoback S (80-90 Cm)

107034
MedicoBack, lumbar belt with integrated electrodes.

Circular Electrodes 32 Mm

281000
Circular electrodes, dimensions 32 mm.

Electrodes Stimex 50x50 20 Pcs

281032
Stimex electrodes 50x50mm, 20 pieces.

Circular Electrodes 50 Mm

282000
Circular silicon electrodes, dimensions 20 mm.

Stimex Electrodes 50x130 Mm

283000
Stimex electrodes 50x130mm

Stimex Electrodes 80x130

283100
Stimex electrodes 80x130mm

Stimex Electrodes 50x50

283400
Stimex electrodes 50x50mm

Stimex Electrodes 50x90

283600
Stimex electrodes 50x90mm
Technical Spec.

Technical Spec.

Output current:
100 mA (with 1 kOhm real)
Frequency range:
0,5 - 120 Hz
Pulse width:
50 x 400 microsec
Pulse type:
rectangular biphasic impulse
Power supply:
integrated rechargeable batteries Ni-mH 4.8 V
Dimensions:
114 x 59 x 27 mm
Weight:
approx. 300g
Conformity:
complies with CEE 93/42
Gallery

Gallery

Logistics

Logistics

Code Repertoire:
330743

Weight, size and volume

Weight, size and volume (+/- 10%)
N° Package Package type Dimension Weight Volume
1 SCATOLA cm 30 x 22 x 9 h kg 1 mc 0.00594
Documents

Documents


Brochure Terapia Tens

Brochure
Language: Italian
DOWNLOAD
PDF 792.53 KB

Tens Eco 2

Brochure
Language: English
DOWNLOAD
PDF 34.34 KB

104062 - User and maintenance manual

User and Maintenance Manual
Language: English
DOWNLOAD
PDF 1.52 MB
Register to access the content

104062 - Declaration of Conformity

Declaration of conformity
Language: English/Italian
DOWNLOAD
PDF 17.5 KB
